IP VoIP SIP AA-600/SM5x Module
The combination of IP Audio + IP Video + SIP VoIP technologies in Networking concentrated in a compact module to overcome the limits of creativity!
IP Audio IP Video VoIP SIP Multicast Web Relay PoE - 12/24V Alarm Input RS-485
The AA-600 series IP modules allow the creation of customized communication devices on a LAN network ranging from VoIP Video Doorphones telephony systems, hands-free intercoms, IP amplifiers for PA (Public Address Audio Paging) broadcasting of announcements and music, up to Actuator Systems of Security and Emergency. The modules are designed to be integrated into devices and systems customized by the customer, for example:
- Conversion of old intercoms into LAN IP video Doorphones
- VoIP Doorphones with customer mechanics
- Emergency-Information columns
- Access and gate control, entrances, gates and barriers
- Use as a communication system for public access machines (Bancomat, Ticket machines, Distributors, etc.)
- Communication, security and music in elevators
- Audio amplification and announcements broadcast on LAN
- Realization of IP SIP speakers
- Signaling, Warning and Emergency systems
The AA-600 modules are two-way communication systems. In the simplest application it is sufficient to connect a microphone, a speaker and a button to create a complete VoIP SIP PoE communication system integrated in the LAN with 2 internal relays that can be remotely activated.
Speaker + AA-600 Module + Microphone
For more realizations other accessories are available:
- Mini USB color camera
- 12 keys telephone vandal-proof keypad
- RFID cards and tag reader
- Additional buttons
- Additional internal 20W audio amplifier
Applications of Communications, Security, Control & Signaling in LAN Network
Integration in telephone and security systems
AA-600 integrates perfectly with VoIP telephony systems (IPPBX) with SIP protocol that can be registered as a normal VoIP phone or in Peer-to-Peer (P2P) mode without a PBX.
Included APP for iOS and Android, PC Sofware
APPs are available for iOS/Android Smartphones, software for Windows PCs is provided for the management of 1 to 16 modules. For larger systems, ADAM management software is available for up to 1,000 modules.
Total Management via LAN, integrated Web Server
Programming, configuration, loading and listening of audio files, firmware update, audio volume adjustment, backup, configuration reset, restart.
Recorded messages
Inside the SD card are recorded sounds and messages for automatic or specific command sending. The messages can be customized by the user and can be loaded remotely via LAN.
Power Supply
The modules are PoE (Power over Ethernet) on the UTP cable, but also allow input from an external power supply.
Target
System Integrators, IP solutions developers
MADE IN ITALY by TEMA
product developed and built in Italy by TEMA which guarantees its support, technical assistance over time, software updating and new future features. Customizations of both hardware and system firmware are possible
Innovative Features and Performances
- Ideal for making custom equipment
- Double internal 2x2W audio amplifier
- Additional 20W max amplifier for external speakers, can be activated/deactivated with DTMF codes
- General night ringtone repeater 2nd SIP account, sounds from files freely customizable by the user
- “SIP Security Info Call” alert/emergency SIP call
- 2 internal relays remotely controllable via LAN network
- 16 RX Multicast channels
- Adjustable volumes separately for all audio channels Multicast/Annoucements/Ringtone
- P2P Peer-to-Peer operation even without IP-PBX
- VoIP connection with SIP Proxy Server protocol
- 802.af integrated PoE can be powered directly on the UTP LAN cable, or with an external power supply or both
- Internal memory with user-customizable audio files of 60sec each (Option up to 8 minutes)
- ”Monitor” function for environmental listening
- ”Push to Talk” function for communication direction
- Possibility of broadcasting a pre-recorded announcement, associated with the entry, or up to 6 announcements by making a call and sending the respective code via telephone
- Message to the calling visitor
- 1 multi-function input activated by external contact
- Programming via LAN, integrated Web Server
- Great versatility, ease of use and programming
- Free APPs developed for iOS and Android smartphones
- Free AA-Videoconsole software for Windows PCs
- ADAM Software for Management up to 1.000 modules
- Possibility to update the firmware remotely via LAN
- Extremely small dimensions 76,5x62x32,5mm
- Wall, table and DIN rail mounting
- Compatibility with all IP-PBXs of the most prestigious brands including Softphones and Asterisk-based systems
- SNMP for remote management
Technical features
| LAN, protocols | TCP/IP Network 100BaseTx, SIP 2.0 |
| Degree of protection | IP20 |
| Power supply | PoE, PoE Injector or Power supply |
| PoE | 802.3af class 0 12,95W |
| Power supply (Opz.) | 230Vac/12-24Vdc-1-2A |
| Messages/Sounds | pre-recorded in the SD internal memory |
| Technology | IMX25 400MHz processor |
| Memory | 256MB Ram, Micro-SD Flash 8GB |
| Contact rating of the 2 internal relays | max 30Vdc – 1,5A |
| Container material | ABS |
| Operating temperature | from -20° to +55°C |
| Storage temperature | from -20° to +65°C |
| Umidity | up to 90% |
| Installation | table, wall, on standard DIN bar |
| Dimensions | 76,5x62x32,5mm |
| Weight | 170gr |
| Basic Audio Amplifier | 2x2W “D” Class |
| Additional amplifier | 20W “D” Class (10W PoE) |
| Bandwidth | 80 – 15.000Hz |
| Connection | SIP Server (IPPBX) or P2P (Peer To Peer) |
| Microphone | omnidirectional electret 30Hz-18KHz |
| RTP Multicast audio Streaming | G.711/G722/16-44,1KHz |
| Audio Communication | Unidirectional and Bidirectional |
| Inputs from external commands | 1 (Alarm) + 1 (Call) |
| Mobile APP | iOS, Android |
| Acoustic signals | tones, pre-recorded messages |
| Signalings | Call LED |
| Programming | user-friendly web interface and password |
| Warranty | 2 years |
| Compatibility | CE, ROHS |
NOTE: the modules are designed to be placed in cabinets or in another closed and protected container.
ADAM Management Software
ADAM Management and Supervision Software up to 1,000 AA-600 systems on the LAN network
APP and VideoConsole for PC
AA-600 standard versions (The devices can be customized on request for specific applications)
| AA-600/… | SM51 | SM51V | SM52 | SM52V |
| Internal Amplifier 2+2W | ● | ● | ● | ● |
| Microphone, speaker, button sockets | ● | ● | ● | ● |
| External Keyboard/Keypad socket | ● | ● | ● | ● |
| RS485/RFID port socket | ● | ● | ● | ● |
| PoE 803.af internal power supply | ● | ● | ● | ● |
| External Vdc/Vac power supply input | ● | ● | ● | ● |
| Internal slot for 10-20W Amplifier | ● | ● | ● | ● |
| Inputs from external alarm contact | 1 | 1 | 1 | 1 |
| Internal relays | 2 | 2 | 2 | 2 |
| Socket for external USB camera | – | ● | – | ● |
| Socket for LED illuminator | – | ● | – | ● |
| 2nd internal amplifier 20W (10W PoE) | – | – | ● | ● |
Optionals and accessories
AA-697/MIC
High sensitivity omnidirectional microphone, cable for call button, in protected ABS case, wired with connector
AA-697/AP3
Waterproof 8 Ohm-3W loudspeaker in ABS plastic enclosure, incorporating a highefficiency LED indication of call in progress, pre-wired with cable and connector
AA-697/CAM
USB HD camera in ABS enclosure wired with 25cm cable and 10-WAY connector
AA-697/CLL
USB HD camera and illuminators board 10 white LEDs, 25cm cable and 10WAY connector
AA-697/KP – AA-697/KV
Backlit vandalproof keypad for indoor/outdoor use in ABS case wired with 25cm cable and 10WAY connector. Also available in indoor version with plastic buttons
AA-697/P16
16 additional buttons interface board. The board is an alternative to the keyboard
AA-697/P1
Steel metal button with 25cm cable
AA-39DL
Plug Power Supply 220Vac/12Vdc-1,0A
AA-39D1A, AA-39E3 /AA-39E6V
AA-39D1A - P. Supply DIN 220Vac/15Vdc-1,0A
AA-39E3 - P. Supply DIN 220Vac/24Vdc-1,5A
AA-39E6V - P. Supply DIN 220Vac/24Vdc-2,5A
AA-39P4
PoE injector 230Vac/48Vdc 0,5A
AA-36
250Vac/16A/4KVA power relay, AC/DC 12V/24V control, 1 change-over contact, LED indicator, for loads up to 230Vac-4.000W
AA-697/DIN
Kit for mounting the modules on a DIN rail consisting of an Abs coupling + 50mm galvanized bracket + 2 screws
AA-697/W4 – W10
4 and 10 way connectorized cables, length 25cm/200cm, free end on the other side
AA-699/L10A/X20R/X10B
Flash warning lights with Xeon lamp or with high brightness LEDs, with a call in progress they add a light signal to the acoustic signal
G2130/G3140/G3240/G3275/…
IP VoIP SIP phones and video phones for internal stations and VoIP/Multicast calls
AD696/CT Multi-Zone Console
Multicast and telephone SIP P2P multi-function Console and multi-zone from 4 to 256 zones
AD696/BM base, AD615/S IP Encoder
Microphone base with Chime, Multicast analog/digital encoder
APP iOS/Android, AA-Videoconsole
APP for iOS and Android, Software VideoConsole for Windows PCs
ADAM advanced management software
Audio Domain & Access Management Software for Windows PC with Multi-Zone console
NOTE: for additional products and accessories see also the series SipComPoint and SipComStage.
Applications
ADAM Audio Domain & Access Management
Advanced software for complete management of all terminals and multi-zone microphone consoles
Learn more >
Announcements Paging and sending of Multicast audio
ADAM is also an Encoder in Multicast channels capable of transmitting announcements from a local microphone connected to the PC on different priority multicast channels, or programmed reception zones, thus transforming the PC into a multi-zone microphone console for the transmission of announcements or pre-recorded audio files. The sending operation can be performed in a few seconds and is interrupted with a simple click.
Audio Quality
The audio of the digital transmission can be chosen in a range up to 44.1KHz for maximum sound quality over LAN.
Software developed in Italy
The software is entirely developed in Italy by TEMA which guarantees the upgrade of the performances and the support over time.
The TEMA complete solutions offer
Tema produces all the necessary components for the realization of IP Paging systems on the LAN network, integrated with the VoIP telephone system, the security system and video surveillance.
- IP-SIP Speakers and Horns, IP-SIP Amplifiers from 4 to 40W
- IP Encoder from analog inputs
- IP Interfaces for traditional analog amplifiers
- Microphone Base and Console
- Centralized management software for Audio Management
VideoConsole
for PC, APP for Smartphone iOS e Android
Free software included
AA-VideoConsole is a software that is supplied free of charge with the AD600 series IP audio devices and the AA-500 and AA-600 series IP video doorphone systems, used to monitor and operate from a single location with 16 IP audio devices and/or IP video doorphones. The software can be installed on one or more PCs (without license limits) with operating system from Windows XP/7/10 or later.
The software allows to see the area framed by the camera in IP video doorphones,
to communicate and remotely operate the relays of the terminals managed in the network, all from the software window itself.
The PC where AA-VideoConsole is installed must be equipped with a sound card and fitted with speakers and a microphone.
It is possible to display up to 16 scenes/devices at the same time and operating with one terminal at a time chosen from those in the window.
The same version for iOS and Android smartphones can be downloaded for free from the respective Applestore and Google Play stores.
Download
| Date | File | Size |
| 01/2020 | Brochure | 2.46 MB |
| 06/2019 | Manual | 4.10 MB |
| 09/2019 | Quick Guide | 1.52 MB |
| 09/2019 | AA697-MIC Datasheet (Microphone) | 472 KB |
| 09/2019 | AA697-AP3 Datasheet (Speaker) | 290 KB |
| 09/2019 | AA697-CAM Datasheet (Camera) | 315 KB |
| 09/2019 | AA697-CLL Datasheet (Camera and white LED illuminator) | 384 KB |
| 09/2019 | AA697-KVKP Datasheet (12 key keyboards) | 465 KB |
| 09/2019 | AA697-P16 Datasheet (16 buttons interface board) | 528 KB |
| 06/2019 | AA697-DIN Datasheet (Kit for mounting in standard DIN rail) | 436 KB |
| 09/2019 | AA697-W Datasheet (Cables with connector) | 358 KB |
